Technical Parameters
| Dimensions sliding table | 2800/3000/3200*320mm |
| maximum cutting panel length | 2800/3000/3200mm |
| maximum cutting panel thickness | 75mm |
| Tilting angle saw blade | 90°mm |
| Saw blade diameter | Ø300mm |
| Scoring saw blade diameter | Ø120mm |
| Speed of main saw blade | 4500/6000rpm |
| Speed of scoring saw blade | 6000/8000rpm |
| Spindle diameter | Ø30mm |
| Spindle of scoring saw diameter | Ø20mm |
| Main motor power | 4.0/5.5Kw |
| Scoring power | 0.75Kw |
| Weight | 680kg |
| Voltage | 380v/50hz 3phase |
| Body packing size | 1960*1100*1100mm |
| Table packing size | 2850/3050/3250*450*300mm |
